Sirena P50

Multi-function piezoelectric sounder, developed with a multichannel technology. P50 A allows seven different types of alarm controllable via independent electric contacts. Versions available with QC M12 connector or M12 cable gland.

Downloads

Beschrijving

Multi-function piezoelectric sounder, developed with a multichannel technology. P50 A allows seven different types of alarm controllable via independent electric contacts. Versions available with QC M12 connector or M12 cable gland.

Extra informatie

Explosieveilig (Ex)

Nee

Technische specificaties

VOLTAGES 12/24V ACDC +/-5%
Mechanical features Self-extinguishing PC body totally protected against vibrations
Mechanical features dust and atmospheric elements.
Mechanical features PDM o-ring on dome and polyuretanic gasket on base
Mechanical features  Can be panel mounted through a M22 hole and secured with the locking ring provided
Mechanical features Electrical connection through QC M12 4 PIN connector or M12 cable gland
Acoustic features Electronic circuit with multitension buzzer
Acoustic features Seven sounds available (Continuous sound
Acoustic features Slow Intermittent Sound
Acoustic features Fast Intermittent Sound
Acoustic features Double Intermittent Sound
Acoustic features Triple Intermittent Sound
Acoustic features Telegraph
Acoustic features Random
Sound frequency 3500+/-100Hz

Goedgekeurd voor

CEPCHZ50_60C°_-30_+50IP65ONCLASS2S_E7TONESDB920_07KG
